| 브랜드 이름: | Lei Kan |
| 모델 번호: | LKXR-XD110 |
Ⅰ. Product Overview
The radar adopts azimuth mechanical scanning and elevation digital beamforming system, which can continuously detect and track moving targets in the area 24/7. It has the advantages of high detection sensitivity, low false alarm rate, and high accuracy.
Ⅱ. Product selling points
1. The detection radius for elf drones is ≥ 5km, for personnel it is ≥ 8km, for vehicles and ships it is ≥ 10km, with an azimuth coverage range of 360 ° and an elevation coverage range of 35 °. The detection performance is not affected by climate and lighting;
2. It can track more than 150 moving targets within the field of view, output real-time information such as target distance, speed, orientation, altitude, type, etc., and achieve suspicious target positioning and warning functions;
3. Shielding and warning areas can be set up to achieve target boundary alarm, alarm log recording, and playback;
4. Support radar photoelectric linkage, guide high-definition cameras to track, capture, and record targets in video;
5. Good compatibility and scalability, easy to integrate with other platforms, supporting multi device networking.
Ⅲ. Product Specifications
|
Parameter |
Value |
|
Frequency |
X-band 9.8–10 GHz |
|
Radar type |
Azimuth mechanical + Elevation DBF |
|
Coverage |
Azimuth 360° |
|
Detection range |
≥5 km (quadcopter) / ≥8 km (person) / ≥10 km (Vehicles and ships) |
|
Blind zone |
≤50 m |
|
Range/Angle acc. |
≤5 m (RMS) / Az & El ≤0.4° |
|
Max tracks |
≥200 |
|
Radial velocity |
1–150 m/s |
|
Antenna speed |
30 rpm (180°/s) upgradeable 60 rpm |
|
Power consumption |
≤220 W |
|
Weight |
≤30 kg |
|
Size |
595×500×85 mm |
|
Protection |
IP65 (main unit IP67) |
Ⅳ. Product Features
1. High data rate and strong tracking ability
2. Low false alarm probability
3. Wide detection range and high accuracy
4. High cost-effectiveness, easy to operate
Ⅴ. Usage scenarios
